Live Streaming

AG01

Live Streaming USB Microphone

A live streaming USB microphone with integrated high-performance mixer.

Studio-quality USB condenser microphone
Modern and retro design with two models in black and white
High resolution (24-bit, 192 kHz) 2-track audio recording and playback
4-pole mini input/output (TRRS) to support new streaming applications
Flexible LOOPBACK function ideal for live streaming or live recording
Mute button for convenience during Live Streaming
Easy control and pro sound with COMP/EQ and 1-TOUCH REVERB
AG Controller (Windows/Mac/iOS) for precise parameter control
Windows/Mac support by USB-C connection
iOS connectivity via Apple Camera Adapter (requires external USB power supply)
Android supported by 4-pole mini input/output (TRRS)
USB-C power input (5 V DC, 900 mA)
3/8″ screw hole for mic stand (with protective cap)
Cubase Al, WaveLab Cast, Cubasis LE and Rec'n'Share are available
“OBS Certified” device. Provides seamless streaming experience with OBS Studio.

AG06MK2

Live Streaming Mixer

A 6-channel live streaming mixer with USB audio interface.

Two condenser microphones can be used simultaneously
+48 V phantom power on CH1-2 input for condenser mics or Dl boxes
Hi-Z input for guitars on CH2
High resolution (24-bit, 192 kHz) 2-track audio recording and playback
4-pole mini input/output (TRRS) to support a wider range of streaming applications
Flexible inputs and LOOPBACK function ideal for live streaming or recording
Mute button for convenient live streaming
Easy control and pro sound with 1-TOUCH effects (COMP/EQ, REVERB and Amp Simulator)
AG Controller (Windows/Mac/iOS ) for precise parameter control
Windows/Mac support by USB-C connection
iOS connectivity via Apple Camera Adapter (requires external USB power supply)
Android supported by 4-pole mini input/output (TRRS)
USB-C power input (5 V DC, 900 mA)
Cubase Al, WaveLab Cast, Cubasis LE and Rec'n'Share are available
“OBS Certified” device. Provides seamless streaming experience with OBS Studio.

AG03MK2

Live Streaming Mixer

A 3-channel live streaming mixer with USB audio interface.

60 mm faders for mic CH1
+48 V phantom power on CH1 input for condenser mics or Dl boxes
Hi-Z input for guitars on CH2
High resolution (24-bit, 192 kHz) 2-track audio recording and playback
4-pole mini input/output (TRRS) to support a wider range of streaming applications
Flexible inputs and LOOPBACK function ideal for live streaming or recording
Mute button for convenient live streaming
Easy control and pro sound with Amp Simulator and 1-TOUCH COMP/EQ, REVERB
AG Controller (Windows/Mac/iOS) for precise parameter control
Windows/Mac support by USB-C connection
iOS connectivity via Apple Camera Adapter (requires external USB power supply)
Android supported by 4-pole mini input/output (TRRS)
USB-C power input (5 V DC, 900 mA)
Cubase Al, WaveLab Cast, Cubasis LE and Rec'n'Share are available
“OBS Certified” device. Provides seamless streaming experience with OBS Studio.

AG08

Live Streaming Mixer

An 8-channel live streaming mixer featuring two phantom power inputs for condenser mics, an integrated USB audio interface, voice changer and sampler.

Two mic/line inputs and two headphone outputs can be used simultaneously
+48 V phantom power on CH1 and 2 for condenser mics or Dl boxes
Four FX preset buttons for CH1, Hi-Z input for guitars on CH2
Three stereo inputs with assignable faders, switchable input source for LINE/USB
4-pole mini input/output (TRRS) on CH7/8
MONITOR outputs (XLR + TRS) and MIX outputs (TRS)
Six sound pads trigger audio samples in real time to add color to live streams
Internal circuitry delivers highest sound-quality in the AG series
24-bit, 48 kHz Multi-channel audio recording and playback (Coexistence of ASIO and WDM)
Flexible inputs and outputs ideal for live streaming
DSP effects (Voice Changer, Amp Simulator, Comp, EQ, Reverb, Delay, Ducker, Maximizer)
AG08 Controller (Windows / Mac / iPadOS) for precise parameter control and detailed audio management
60 mm faders and Mute buttons for each input
Foot switch functionality for more versatile system control
Windows / Mac support via USB-C connection
iPadOS connectivity via Apple Camera Adapter (requires external USB power supply)
Android supported by 4-pole mini input/output (TRRS)
USB-C power input (5 V DC, 1.5 A)
Cubase Al, WaveLab Cast, Cubasis LE are available
